Photo 1: We constructed a sample frame. Note that the binding strips on the tiles can be spaced so far apart that the tile is only stapled onto every second batten. The spacing of the binding tiles can also be adjusted to accommodate branding spaces on exciting roofs.
Photo 2: We stapled a Fiber Indian Ocean edge tile at the bottom onto the frame.
Photos 3, 4, 5 and 6: The ceiling tiles are then stapled from the bottom to the top with rustic side of the tile on the underside, the smooth side to the top, until the complete frame is covered.
Photos 7, 8, 9 and 10: A FR-MO Board is then placed on top of the ceiling tiles stapled onto the frame. Note that the color of the waterproof layer can match the color of the Fiber Synthetic Tiles. The waterproofed FR-MO Board is screwed.
Photos 11 and 12:See the sample board lifted up by Danie, Dawie and some members of our team to show the bottom and top sides.Our goal to get the same “inside” and “outside” look has been achieved.
